Epoxy Coated Steel Casework
Industrial-strength steel casework with a fusion-bonded epoxy finish — engineered for chemical resistance, structural durability, and long-term performance in demanding laboratory environments.
Engineered for the Toughest Lab Conditions
Our epoxy coated steel casework combines heavy-gauge construction with a chemically resistant finish to deliver storage and workspace solutions that perform reliably for decades.
Fusion-Bonded Epoxy Coating
Electrostatically applied and oven-cured epoxy powder coat creates a seamless, pinhole-free barrier that resists chemicals, corrosion, and abrasion far better than paint.
Heavy-Gauge Steel Construction
Fabricated from 18- and 16-gauge cold-rolled steel, our casework delivers structural rigidity that holds up under heavy loads and daily lab use without warping or flexing.
Chemical Resistance
The epoxy finish withstands exposure to acids, bases, solvents, and common lab reagents — protecting both the casework and the personnel working around it.
Modular Configuration
Base casework units, wall casework units, tall storage casework units, and specialty modules combine to create fully custom layouts that fit any lab footprint and workflow.
Integrated Hardware
Full-extension drawer slides, adjustable shelving, and heavy-duty hinges are standard — all rated for lab-grade loads and long-term daily operation.
Compliant & Certified
Specified and built to SEFA 8 standards for steel laboratory furniture. Available in a range of standard and custom colors to match your facility requirements.
Standard Specifications
Custom specifications, dimensions, and finishes available. Contact us for project-specific requirements.
Catalog Numbers
Reference USLabs catalog numbers when submitting RFQs, purchase orders, or architectural submittals. All SKUs follow the format USL-ECS-[Type]-[Width].
Unit Type Reference
All diagrams show front elevation view.
| Cabinet Type | 18" | 24" | 30" | 36" | 48" |
|---|---|---|---|---|---|
| Base Casework Unit — Two Drawer/Two Door | USL-ECS-B-2D2D-18 | USL-ECS-B-2D2D-24 | USL-ECS-B-2D2D-30 | USL-ECS-B-2D2D-36 | USL-ECS-B-2D2D-48 |
| Base Casework Unit (One Door) | USL-ECS-B1-18 | USL-ECS-B1-24 | — | — | — |
| Base Casework Unit (Two Door) | — | — | USL-ECS-B2-30 | USL-ECS-B2-36 | USL-ECS-B2-48 |
| Base Casework Unit — Drawers | USL-ECS-BD-18 | USL-ECS-BD-24 | USL-ECS-BD-30 | USL-ECS-BD-36 | USL-ECS-BD-48 |
| Open Base Casework Unit | USL-ECS-B-OP-18 | USL-ECS-B-OP-24 | USL-ECS-B-OP-30 | USL-ECS-B-OP-36 | USL-ECS-B-OP-48 |
| Wall Casework Unit (One Door) | USL-ECS-W-18 | USL-ECS-W-24 | — | — | — |
| Wall Casework Unit (Two Door) | — | — | USL-ECS-W-30 | USL-ECS-W-36 | USL-ECS-W-48 |
| Wall Casework Unit (One Glass Door) | USL-ECS-W-1G-18 | USL-ECS-W-1G-24 | — | — | — |
| Wall Casework Unit (Two Glass Door) | — | — | USL-ECS-W-2G-30 | USL-ECS-W-2G-36 | USL-ECS-W-2G-48 |
| One Glass Door Left Wall Casework Unit | USL-ECS-W-1GL-18 | USL-ECS-W-1GL-24 | — | — | — |
| One Glass Door Right Wall Casework Unit | USL-ECS-W-1GR-18 | USL-ECS-W-1GR-24 | — | — | — |
| Open Wall Casework Unit | USL-ECS-W-OP-18 | USL-ECS-W-OP-24 | USL-ECS-W-OP-30 | USL-ECS-W-OP-36 | USL-ECS-W-OP-48 |
| Tall Open Storage Casework Unit | USL-ECS-T-18 | USL-ECS-T-24 | USL-ECS-T-30 | USL-ECS-T-36 | USL-ECS-T-48 |
| Tall Casework Unit — One Glass Door | USL-ECS-T-1G-18 | USL-ECS-T-1G-24 | — | — | — |
| Tall Casework Unit — Two Glass Door | — | — | USL-ECS-T-2G-30 | USL-ECS-T-2G-36 | USL-ECS-T-2G-48 |
Custom colors, dimensions, and configurations available. Additional dimensions and other casework designs available upon request. Contact us for project-specific SKUs or to request a full spec sheet.
Lab Bench Catalog Numbers
Epoxy coated steel lab benches are available in two depths and six lengths. All benches are 36" high. SKU format: USL-ECS-LB-[Depth]D-[Length]L-[M/F] where M = Mobile (casters) and F = Fixed.
Lab Bench Type Reference
All diagrams show front elevation view. All benches are 36"H standard.
| Depth | 24"L | 36"L | 48"L | 60"L | 72"L | 96"L |
|---|---|---|---|---|---|---|
| 36"H × 24"D | USL-ECS-LB-24D-24L | USL-ECS-LB-24D-36L | USL-ECS-LB-24D-48L | USL-ECS-LB-24D-60L | USL-ECS-LB-24D-72L | USL-ECS-LB-24D-96L |
| 36"H × 30"D | USL-ECS-LB-30D-24L | USL-ECS-LB-30D-36L | USL-ECS-LB-30D-48L | USL-ECS-LB-30D-60L | USL-ECS-LB-30D-72L | USL-ECS-LB-30D-96L |
| Undermount CaseworkMounts below bench surface | USL-ECS-UC-24L | USL-ECS-UC-36L | USL-ECS-UC-48L | USL-ECS-UC-60L | USL-ECS-UC-72L | USL-ECS-UC-96L |
All lab benches are 36"H. Additional dimensions and other casework designs available upon request. Contact us for project-specific SKUs.
Mobile Lab Carts
Epoxy coated steel mobile lab carts provide flexible, moveable storage and work surfaces throughout the lab. Available in two heights and multiple widths. SKU format: USL-ECS-MC-[Height]H-[Width]W.
Mobile Lab Cart Type Reference
All diagrams show front elevation view. Casters included on all mobile carts.
| Height | Description | 18"W | 24"W | 30"W |
|---|---|---|---|---|
| 30"H | Under-bench height, with casters | USL-ECS-MC-30H-18W | USL-ECS-MC-30H-24W | USL-ECS-MC-30H-30W |
| 36"H | Bench-height, with casters | USL-ECS-MC-36H-18W | USL-ECS-MC-36H-24W | USL-ECS-MC-36H-30W |
All mobile lab carts include locking casters. Additional widths and configurations available upon request. Contact us for project-specific SKUs.
Ready to spec your casework?
Our team will help you design the right casework configuration for your lab — from a single run of base casework units to a complete multi-room build-out.
